Long Column Lifetimes and Excellent Performance
Ultra-pure, metal-free silica (99.99 % purity) is the back bone of all Luna material. The resulting high quality particles have a surface smoothness, pore structure, and pore consistency to ensure a more uniform particle shape and greater reproducibility.

Waters® Symmetry®

Proven Reproducibility
For carboxyl‚ carbonyl‚ and amine containing compounds‚ Luna CN columns offer a unique polar selectivity in reversed phase and normal phase modes. Luna CN columns provide sharp peaks and great reproducibility run-to-run‚ column-to-column and batch-tobatch. State of the art modification of the silca surface ensures improved resistance to bonded phase hydrolysis providing one of the most stable CN phases on the market. The result:
- Excellent polar selectivity
 - Improved peak shapes
 - One of the most stable CN columns under reversed phase or normal phase conditions
 - pH stable from 1.5 to 7.0

Phthalate Esters
|
 Column:
 Luna 5 μm CN
 |
|
|
 Dimension:
 150 x 4.6 mm
 |
|
|
 Part No.:
00F-4255-E0
 |
|
|
 Mobile Phase:
A: Hexane B: Methylene chloride/Methanol (80:20)‚ A/B (99:1)
 |
|
|
 Gradient:
Time (min)
 0
 |
 %B
35  |
|
 Flow Rate:
1.0 mL/min
 |
|
|
 Temperature:
Ambient
 |
|
|
 Detection:
UV @ 254 nm
 |
|
|
 Sample:
1. Di-n-octyl phthalate 2. Bis (2-Ethylhexyl) phthalate 3. Butylbenzyl phthalate 4. Di-n-butyl phthalate 5. Diethyl phthalate 6. Dimethyl phthalate
 |
|
